SF-SAC1019iOS-PLUS-D3.9-105D V1.0
SINCEREFIRST
| This OV9734 CMOS Sensor 3.9mm Diameter 720P@30fps Wide Angle USB2.0 Separate Support IOS System Endoscope Camera Module is a miniature high-definition imaging module tailored for close-range, wide-angle visual scenarios in confined spaces, perfectly compatible with portable devices and narrow cavity detection. Built with the high-performance OV9734 sensor, it delivers stable 720P@30fps image output via YUV and MJPEG formats, presenting clear and delicate imaging to meet daily high-definition observation demands. Its 105° diagonal wide viewing angle greatly expands close-range coverage and effectively reduces detection blind spots, while distortion controlled below -6% guarantees regular and natural image presentation. The 3.9mm ultra-small probe reinforced with a round steel sleeve enhances structural durability and passes smoothly through narrow cavities and thin pipelines. Equipped with a USB2.0 Type-C female port and built-in UVC protocol, it supports driver-free plug-and-play operation, compatible with iOS and other mainstream devices to simplify deployment and integration procedures. Compliant with RoHS standards, it integrates miniaturized structure, wide-angle performance and multi-system compatibility, offering reliable and convenient visual solutions for various narrow-space inspection scenarios. |  |
iOS System Compatibility: Supports iOS device connection and normal operation, expanding applicable terminal scenarios.
105° Ultra-Wide Coverage: Features a 105° diagonal field of view to expand close-range monitoring range and eliminate blind areas.
Stable 720P Imaging: Provides fluent 720P@30fps output with clear picture quality for daily high-definition observation.
Driver-Free Integration: Built-in UVC protocol enables direct connection with mainstream devices, achieving fast and convenient deployment.
Product Name | 3.9mm Diameter USB2.0 Endoscope Camera Module |
F.NO | 4.8 |
| Focus Length | 1.35mm |
| Resolution | 720P |
| Sensor Type | OV9734 |
| Function | Support UVC Protocol IOS |
FOV(D) | 105°*90°*60° |
Waterproof | IP67 |
Focusing Range | 10mm~100mm |
Diameter | 3.9mm |
| Distortion | <-6% |
Output | USB2.0 UVC |
Connector Type | Type-C |
Output Format | YUV/MJPEG |
Brand | Sincerefirst |
Thin Pipeline Endoscopy: Can observe internal defects and blockages of pipelines and cavities above 3.9mm by utilizing its ultra-small passable probe.
Portable Wide-Angle Inspection: Can be installed on handheld devices to complete large-range rapid on-site imaging with its wide-angle performance.
Embedded Wide-Angle Module: Can serve as a built-in wide-angle imaging unit for small equipment and instruments to realize integrated visual collection.
Close-Range Wide-Angle Monitoring: Can conduct blind-spot-free monitoring for narrow spaces and corners relying on its broad field of view.
