When customers choose an endoscope camera module, they often compare only resolution or diameter. But in real medical, dental, veterinary and industrial inspection devices, the final user experience depends on more practical factors: image shape, frame rate, lighting, waterproof support, working distance, FOV, cable length and mechanical integration.
The SF-C1019USB-1000P-D3.9-PRO is a 3.9mm USB endoscope camera module designed for compact close-range visualization. It uses the ES101 sensor, supports YUV / MJPEG output at 1000×1000@60fps, integrates 4pcs 0402 LEDs, supports IP67, and provides multiple FOV and focusing range options.
For OEM customers, this model is especially useful when the project needs a compact camera head, smoother live viewing, square-format imaging, built-in illumination and waterproof support in a small-diameter endoscope module.
Many endoscope camera modules use rectangular image formats such as 1280×720 or 1920×1080. These formats can work well for many devices, but some inspection applications benefit from a more balanced square-format image.
A 1000×1000 output can help customers capture a more symmetrical viewing area around the camera center. This can be useful in compact cavities, pipe-like spaces, circular inspection areas or applications where the user needs balanced top-bottom and left-right visibility.
The 60fps output also helps provide smoother live video when the probe moves during inspection. For handheld tools, portable endoscope devices and real-time visual guidance, smoother video can improve user operation and reduce the discomfort caused by motion.
The SF-C1019USB-1000P-D3.9-PRO is best positioned as a compact 3.9mm 1000P USB endoscope camera module for close-range OEM visualization.
It is suitable for projects that need:
1000×1000 square-format image output
60fps smooth live viewing
D3.9 compact camera head
IP67-supported structure
Built-in 4pcs LED illumination
Multiple FOV options
Multiple focusing range options
USB-based device integration
It should not be positioned as a dimmable LED module, because the PRO version is the non-dimmable version of the PLUS model.
The D3.9 camera head is suitable for compact medical, industrial and inspection devices where a larger 5mm or 6mm camera module may be difficult to integrate.
The ES101 sensor supports 1000×1000 output, giving customers a square-format imaging option for close-range endoscope visualization.
The 60fps output helps improve image smoothness when the camera moves during operation. This is useful for handheld inspection tools and compact endoscope devices where the user needs real-time visual feedback.
The integrated 4pcs 0402 LEDs provide local illumination inside dark cavities. For endoscope applications, lighting is often one of the most important factors affecting usable image quality.
IP67 support makes this module more suitable for applications where moisture, cleaning, liquid exposure or harsh inspection conditions may be involved. Final waterproof performance should still be verified after integration into the customer’s complete device structure.
The module supports 95°, 100°, 110°, 120° and 140° FOV options. This gives customers flexibility when choosing between focused observation and wider cavity visibility.
Available focusing ranges include 4–10mm, 5–50mm, 5–100mm and 10–100mm. This helps customers match the optical configuration to the real working distance of the final device.
The 1000×1000 output gives customers a balanced square view, while the available wide FOV options help support broader cavity observation.
The 60fps output helps provide smoother live video during movement, which can improve real-time operation and viewing comfort.
The IP67-supported design helps customers evaluate this module for inspection devices that require waterproof or moisture-resistant structure. Final testing should be performed at the complete device level.
The built-in 4pcs LEDs support local illumination. Since the PRO version is non-dimmable, it is more suitable for applications where fixed LED brightness is acceptable.
The multiple focusing range options help customers choose the right lens configuration based on actual working distance instead of forcing one focus range into every application.
The SF-C1019USB-1000P-D3.9-PRO can be evaluated for:
Industrial borescope devices
Pipe and cavity inspection tools
Medical visualization device evaluation
Dental and oral inspection devices
Veterinary endoscope systems
Portable USB inspection devices
Maintenance inspection tools
OEM endoscope device development
For medical-related projects, this module should be evaluated as an imaging component. Final compliance, cleaning validation, safety testing and certification should be handled according to the complete device and target market.
Choose this model when your project needs:
D3.9 compact camera head
1000×1000 square-format output
60fps smooth live viewing
Built-in LED illumination
IP67 support
USB image output
Multiple FOV options
Multiple focus range options
Fixed LED brightness
Compact separate-type integration
It is especially suitable for customers who need a small waterproof-supported USB endoscope camera module with smooth live video and flexible optics.
Choose another module if your project needs:
Adjustable LED brightness
Higher resolution such as 2MP, 5MP or 12MP
Very small diameter below 3.9mm
A finished plug-and-play consumer endoscope
Advanced AI inspection
Long-distance observation beyond the available focus range
Specific medical compliance at module level
The best model should be selected according to the real application, not only by resolution or diameter.
After receiving samples, customers should test:
Image smoothness during probe movement
Brightness of fixed LEDs in the real cavity
Reflection on wet or shiny surfaces
Selected FOV at actual working distance
Focus clarity in the target range
IP67 performance after final device assembly
Cable routing and signal stability
Host compatibility with YUV / MJPEG output
Mechanical fit of the D3.9 front-end structure
A desktop test is only the first step. The module should be tested inside the customer’s real device structure or a simulated application environment.
Before requesting samples, customers should provide:
Application scenario
Medical, dental, veterinary or industrial direction
Required diameter
Required frame rate
Preferred image shape
Working distance
FOV requirement
Need for fixed or adjustable lighting
Waterproof requirement
Cable length requirement
Host device or software platform
Sample quantity
Estimated production volume
Mechanical drawing if available
This information helps SincereFull evaluate whether SF-C1019USB-1000P-D3.9-PRO fits the project or whether another endoscope camera module should be recommended.
The SF-C1019USB-1000P-D3.9-PRO is a compact 3.9mm USB endoscope camera module for customers who need 1000×1000@60fps output, built-in LEDs, IP67 support and flexible optical configuration.
Its value is not only “1000P.” The real value is the combination of square-format imaging, smooth live video, compact diameter, waterproof support, multiple FOV options and multiple focusing ranges for OEM device integration.
Need a compact 3.9mm 1000P USB endoscope camera module for your medical or industrial device?
Send your application, working distance, FOV requirement, waterproof requirement and lighting needs to SincereFull. Our team can help evaluate whether SF-C1019USB-1000P-D3.9-PRO fits your project or recommend a more suitable endoscope camera module.
