SF-C016USB-D1.4
SINCEREFIRST
This 1.4mm Diameter Micro OCHTA10 CMOS Sensor USB2.0 Interface Supporting UVC Protocol Endoscope Camera Module,With an ultra-thin 1.4mm diameter, this micro endoscope can access extremely confined spaces that conventional cameras cannot reach, such as narrow pipelines and gaps in precision instruments. The steel sheel not only reinforces structural strength but also supports an IP67 waterproof rating, ensuring stable operation in harsh environments—including humidity, oil contamination, and brief immersion—meeting the stringent requirements of industrial and medical applications.The 3–30mm focal range is optimized for close-up observation, and a minimal 0.175mm depth of field enables micron-level precision focusing at very short working distances. This makes the module particularly suitable for inspecting tiny scratches, foreign objects, solder joints, and other microstructures, significantly improving detection accuracy.An f/2.8 large-aperture lens ensures sufficient light intake, maintaining image brightness even under low-light conditions. The 100°×100° wide-angle field of view allows single-shot imaging to cover larger inspection areas, reducing probe movement and improving efficiency. With distortion below -11%, the wide-angle design supports comprehensive observation in narrow spaces.The standard USB 2.0 interface, combined with the UVC plug-and-play protocol, provides immediate compatibility with Windows, Linux, Android, and other platforms. Dual-format output—YUV and MJPEG—offers flexibility based on application needs: MJPEG conserves bandwidth, while YUV preserves higher levels of original image detail.The 5-pin interface (VBUS, D+, D-, GND, LED control) integrates power supply, data transmission, and illumination control, simplifying overall system design.Typical applications include:1.Internal inspection of industrial micro pipelines，2.Solder quality inspection of precision electronic components3.Maintenance of micro cavities in medical instruments，4.Detection of minor blockages in automotive oil lines，5.Observation and restoration of delicate cultural relic areas，6.Laboratory recording of microscopic samples.This module delivers high-definition visualization in ultra-confined spaces at the 1.4mm scale, making it ideal for professional, precision-oriented environments. |  |
Product Advantage ◢
1. Extreme Miniaturization Design: With a lens diameter of just 1.4mm and reinforced stainless-steel casing, this module can access extremely narrow pipelines, precision instrument gaps, and microchannels in medical devices—areas unreachable by conventional cameras—enabling true full-angle inspection.
2. Macro High-Definition Imaging: The 3–30mm focal range combined with an ultra-small 0.175mm depth of field allows micron-level precise focusing at very short working distances. It clearly captures minute scratches, foreign objects, solder joints, and other microstructures, meeting the demands of precision inspection.
3.Adaptability to Fully Dark Environments: The f/2.8 large-aperture lens ensures ample light intake, and optional LED illumination supports stable imaging even in complete darkness (0 lux). IP67 waterproofing and the stainless-steel housing ensure long-term reliable operation in humid, oily, dusty, or otherwise harsh conditions.
4.Plug-and-Play High Compatibility: The USB 2.0 interface supports UVC driver-free operation, compatible with Windows, Linux, Android, and other platforms. Dual-format output (YUV and MJPEG) provides flexible adaptation to bandwidth and application requirements. The 5-pin interface integrates power, data transmission, and LED control, significantly simplifying system integration.
1.Industrial Micro-Pipeline Inspection: Suitable for ultra-thin pipelines with diameters above 1.5mm, such as water, air, or oil tubes. Capable of clearly detecting corrosion, foreign object blockages, and weld seam defects. Widely applied in precision manufacturing, energy, and chemical industries.
2.Electronic Component Quality Inspection: Ideal for PCB solder joint sampling, micro-connector pin deformation observation, and chip underside crack detection. The 1.4mm diameter allows access between circuit board layers and component gaps for non-destructive testing.
3.Medical Minimally Invasive Device Support: Can be integrated into ultra-thin bronchoscopes, ear canal endoscopes, dental inspection tools, and similar devices. The 3–30mm working range adapts to human cavity observation needs, providing clear and reliable real-time imaging for clinical diagnosis.
4.Precision Instruments and Cultural Heritage Preservation: Suitable for watch movement maintenance, optical lens internal inspection, and micro-area restoration of cultural relics. With 400×400 resolution, it balances detailed reproduction and manageable data volume within limited pixel constraints.
Product Name | Miniature endoscope camera module |
Image Sensor | OCHTA10 |
Image Device | USB2.0 Interface |
Pixel | 400*400 |
Diameter | 1.4mm |
Focusing Range | 3-30mm |
Field of View (FOV) | 100 (Horizontal) |
TV Distortion | < -11% |
Aperture | F2.8 |
Format | YUV&MJPG |
FAQ ◢
1. What are the driver installation requirements for this module?
This module employs the USB 2.0 UVC standard protocol. When connected to mainstream terminal devices, it requires no standalone drivers and enables direct image data transmission.
2. What is the specific range of imaging distortion parameters?
The TV distortion value of this module's optical lens is controlled within -11%, ensuring stable imaging characteristics across a wide field of view.
A large depth of field (e.g., 5mm to 50mm) can clearly display near and far objects simultaneously, reducing the need for frequent focusing, which is suitable for endoscopic surgery. A shallow depth of field is used to highlight specific plane details, such as skin inspection. This module’s 3–30mm focus range balances both needs, adapting to different inspection scenarios.
The medical-grade version adopts an IP68 waterproof seal, and its housing material is high-temperature and high-pressure resistant (such as epoxy resin), withstanding 134°C steam sterilization. Industrial-grade modules can be customized with an IP54 splash-proof design to meet on-site application requirements.
The standard version comes with a Micro USB-5P interface. For specific needs, common interfaces including USB3.0, HDMI, and SDI are also customizable. Industrial scenarios can choose PoE power supply interfaces, while medical devices can integrate dedicated medical image interfaces (such as DVI-Med).
Are you looking for a reliable ultra-miniature endoscope camera module for medical, industrial, or research projects? The 1.2mm USB Endoscope Camera Module is your optimal choice. With its unmatched miniaturization and superior optical performance, it can solve your most challenging micro-inspection problems. Inquire Now to get a customized quote, or click Add to Basket to place your order directly. Our professional technical team will provide you with one-stop after-sales service to ensure your application runs smoothly.
