| Quantity: | |
|---|---|
SF-C50USB-D1.5-Side
SINCEREFIRST
The OCHFA10 ultra-fine diameter side-looking medical endoscope camera module has a 1.5mm ultra-fine diameter design and is equipped with high-performance medical-grade sensors to provide a breakthrough solution for minimally invasive diagnosis and treatment. The module has a wide focus range of 5-50mm, combined with an ultra-short focal length of 0.418mm and a large aperture of F5.0, enabling clear imaging of tissue microstructures at extremely close distances. The 86°×86° wide viewing Angle design provides a wider viewing range of the operating field, and the TV distortion is strictly controlled within -11% to ensure that the image edge is distortion free. The module adopts side-looking optical structure, which is especially suitable for lateral observation in narrow cavity, such as bronchoscopy, biliary exploration and other complex clinical application scenarios. Its sophisticated optical system delivers high-contrast, high-resolution real-time images that meet the demanding detail requirements of minimally invasive surgery |  |
1. Lateral view structure, breaking through the limitations of traditional endoscopes: unique lateral observation design can explore the lateral wall lesions (such as bronchial branches and bile duct stenosis) that are difficult to reach by traditional direct view endoscopes.
2. Plug and play, strong compatibility: standard USB interface, can quickly access medical imaging systems, workstations or portable devices, support real-time video and image storage.
3. F5.0 large aperture, improve imaging brightness in low light environment, to ensure clear examination of dark cavity (such as digestive tract, blood vessels).
Industrial Video Borescope
Pipeline Inspection Borescope
Medical Inspection Borescope
Sensor | OCHFA10 |
Lens Material | Plastic |
Connector | Mini USB-5P |
Diameter | 3.6mm |
F No. | 5.0 |
Basic tolerance | ±0.1mm |
Focusing Range | 5~50mm |
Focal Length | 0.418mm |
F Number | 4.0 |
FOV(H*V) | 86°*86° |
TV Distortion | ＜-11% |
FAQ
1. Can I buy a used medical endoscope module?
Sterilization history, sensor wear (e.g. number of hours on) must be confirmed, and must be re-certified by the original manufacturer, otherwise there is a risk of cross-infection or performance.
2. How to evaluate the cost performance of the module?
For comprehensive resolution, durability, and after-sales support (such as medical modules that require calibration services from manufacturers), industrial scenarios can prioritize MTBF (mean time to failure) indicators.
3. What is the difference between medical and industrial endoscope modules?
The medical module emphasizes biocompatibility, sterilization and high image quality, and needs to comply with FDA/CE certification; Industrial modules focus on durability (such as corrosion protection), wide temperature operation (-20°C to 70°C), and special light sources (such as UV).
4. How does the endoscope camera module work?
The endoscope camera module collects the internal image through the front optical lens, converts it into electrical signal by CMOS or CCD sensor, and then optimizes it through image processing chip for noise reduction and enhancement, and finally outputs high-definition video signal. Some modules support wireless transmission or fiber optic signal transmission, suitable for medical or industrial inspection scenarios.
5. How to achieve waterproof and sterilization design?
The medical-grade module uses IP68 waterproof seal, the housing material is resistant to high temperature and pressure (such as epoxy resin), and can withstand 134°C steam sterilization. Industrial modules may require only a splash proof design (IP54).
