SF-C0310USB-D3.6-L16
SINCEREFIRST
The SF-C0310USB-D3.6-L16 micro endoscope camera module is a high-precision medical imaging device independently developed by SincereFull. It is specially designed for minimally invasive medical procedures, with an ultra-compact 3.6mm diameter and a 1MP OV9734 CMOS sensor as the core. The module supports adjustable focus in the range of 40–80mm, and outputs YUV2/MJPEG signals through USB2.0 OTG interface. It can achieve 30fps VGA and 15fps QVGA real-time imaging, with low power consumption and extremely low signal delay. Complying with the UVC protocol, it supports plug-and-play on mainstream systems, and can be seamlessly integrated into various medical endoscope equipment, providing clear and stable imaging support for clinical diagnosis and minimally invasive surgery.
The 3.6mm ultra-fine diameter makes the module the ideal choice for minimally invasive medical operations such as gastroscopy and enteroscopy. It can enter the human body through tiny incisions or natural cavities, minimizing the trauma to patients and accelerating postoperative recovery.
Equipped with a 2.63mm focal length lens and a 1MP OV9734 sensor, the module supports a 40–80mm adjustable focusing range. It can flexibly adapt to the imaging needs of different depth positions in the body, ensuring that the lesion area is clearly visible, and helping doctors to make accurate diagnosis.
The module adopts the USB2.0 OTG interface and is fully compatible with the UVC protocol, realizing true plug-and-play without installing additional drivers. It has the characteristics of low power consumption, which can prolong the working time of portable medical equipment and reduce the burden of system power supply.
With a TV distortion rate of less than 1% and a 70° field of view, the module can capture high-fidelity images with minimal distortion. It can truly restore the actual situation of the internal tissues of the human body, avoiding misdiagnosis caused by image distortion.
Parameter | Details |
Product Name | 3.6mm 1MP Micro Medical Endoscope Camera Module |
Image Sensor | OV9734 CMOS |
Resolution | 1MP |
Focal Length | 2.63mm |
Focusing Range | 40–80mm |
FOV (D) | 70° |
TV Distortion | < -1% |
Module Diameter | 3.6mm |
Interface | USB2.0 OTG (UVC Compliant) |
Frame Rate | 30fps (VGA) / 15fps (QVGA) |
Brand | SincereFull |
The ultra-compact 3.6mm diameter enables the module to smoothly enter the esophagus, stomach, and intestines, capturing clear images of the digestive tract mucosa. It helps doctors detect gastritis, gastric ulcers, intestinal polyps, and other lesions in time.
It provides real-time high-definition imaging support for minimally invasive surgeries such as laparoscopic and thoracoscopic operations. Surgeons can observe the internal operation field through the module, improving the accuracy and safety of the operation.
In the field of medical equipment maintenance, it can be integrated into flexible shaft drain pipe cleaners to detect the blockage and dirt accumulation inside the medical pipeline, ensuring the cleanliness and safety of the pipeline.
It can be embedded into portable medical endoscope devices, realizing on-site rapid diagnosis in clinics, community hospitals, and other places. It reduces the dependence on large medical equipment and improves the accessibility of medical services.
An endoscope camera module is an advanced optical imaging device that integrates a sensor, lens, and transmission interface. Its core value lies in enabling non-invasive observation of internal structures that are difficult to reach by the naked eye. In the medical field, it helps doctors accurately observe internal organs and tissues, detect lesions in time, and improve the efficiency of diagnosis and treatment. In industrial and scientific research fields, it can be used for non-destructive testing and microscopic imaging.
SincereFull is a top-tier manufacturer of endoscope camera modules with ten dust-free and sterile automated workshops. All employees undergo systematic training and strictly abide by the cleaning and operation specifications. Each module has to go through multi-stage comprehensive testing, and the pass rate exceeds the industry standard. We have an independent R&D team to carry out technological innovation and product optimization according to customer needs.
We can provide a variety of customization services, including choosing between integrated and separated module structures, customizing the diameter size of the module, adding or removing steel sleeves, and customizing the type and brightness of LED lights. We can also adjust the focal length, field of view, and other parameters according to the specific application scenarios of customers.
Are you in need of a high-precision micro endoscope module for minimally invasive medical equipment? Don't miss the SF-C0310USB-D3.6-L16 module of SincereFull! Contact us immediately to obtain the detailed product manual and exclusive customization plan. We are committed to providing you with the most reliable medical imaging solutions and helping your medical equipment products stand out in the market!
