SF-C2016USB-1080P60-D6
SINCEREFIRST
| This 6mm Diameter 1080P HD Iamge OV2740 CMOS Sesnor USB Interface Endoscope Camera Module is Designed for confined and demanding environments, this 6mm USB endoscope camera module delivers robust performance in a compact form factor. At its core, it features a high-performance OmniVision OV2740 sensor capable of outputting smooth 1080P video at 60fps. Leveraging Back-Side Illumination (BSI) technology and an F5.9 aperture, the module ensures clear, blur-free imaging even in low-light conditions.The optical system combines a 140° ultra-wide field of view with a flexible 8-80mm focus range, capturing both broad scenes and intricate micro-details with minimal distortion (TV distortion < -50%). Housed in a durable stainless steel sheel, the probe meets IP67 standards, making it resistant to water, dust, and humidity. |  |
High-Resolution Imaging: Delivers strong low-light sensitivity, 1080P@60fps blur-free video, low distortion, and precise detail reproduction.
Broad Optical Compatibility: Ultra-wide angle paired with a wide focus range eliminates frequent adjustments, adapting to multi-distance observation needs.
Robust Environmental Resilience: Industrial steel shell with IP67 dust/water resistance withstands humid, oily, and dusty complex scenarios.
User-Friendly Operation: Driver-free across Windows/Android/Linux systems, enabling direct connection to mobile phones, computers, and more.
ENT Diagnostic Endoscopy: Upgrades Olympus/Pentax scopes; 6mm probe reaches nasal sinuses, 140° FOV detects eardrum perforations, and dimmable LEDs prevent mucosal irritation.
Aero-Engine Borescopy: Serves as a GE/Rolls-Royce maintenance probe; passes through cooling holes to detect 0.02mm cracks, with IP67 protection resisting high-temp oil mist.
Automotive Powertrain Inspection: Compatible with Bosch/Snap-on hosts; detects cylinder carbon deposits and gear wear, while 60fps imaging captures dynamic piston clearance changes.
Precision Mold Quality Control: Works with Mitutoyo/Keyence systems; identifies mold burrs and die chipping, with 8mm macro focus spotting ±0.01mm deviations and wide dynamic range reducing metal glare.
Product Name | Endoscope Camera Module |
Features | 6mm Endoscope Camera Module |
Interface | USB2.0 ,UVC |
Sensor | OV2740 |
Focusing Range | 8mm-80mm |
Array Size | 1920x1080 |
Focal Length | 1.05mm |
TV Distortion | <-50% |
F .NO | 5.9 |
Fov(D) | 140° |
| LEDs | 6pcs |
| Pixel | 2MP |
Yes. The module adopts the standard USB UVC protocol and supports OTG. Through a simple adapter, it can be connected to most Android phones or tablets for plug-and-play viewing.
IP67 indicates that the module is completely protected against dust ingress and can withstand immersion in 1-meter deep clear water for a short period (usually tested for 30 minutes). This makes it suitable for environments that are humid, require washing, or disinfection.
The module can be supplemented with light through integrated LED fill lights. Additionally, the OV2740 sensor's large pixel size and BSI technology inherently enhance low-light sensitivity. The combination ensures usable images can be obtained even in dark environments.
Thanks to MJPEG hardware compression output, the module places less pressure on USB bandwidth and computer decoding. For lower-configuration devices, you can also select 720P resolution or YUV format in software to balance image quality and smoothness.
