SF-SAC1019USB-720P-D3.9-Max-TyPec-105D V1.0
SINCEREFIRST
The 1MP HD Fixed Focus OV9734 CMOS Sensor USB Separate Endoscope Camera Module with IP67 Waterproof is designed for OEM inspection devices that require a compact probe, reliable mechanical structure, and convenient USB Type-C connection. Unlike standard USB cameras used for general imaging, this module is optimized for internal inspection tasks where the camera needs to enter narrow spaces and provide real-time visual feedback. The combination of a D3.9mm camera head, 105° viewing angle, Separate Type structure, and Type-C interface provides a practical balance between accessibility, viewing coverage, and device integration flexibility. The reinforced small-diameter probe design helps improve mechanical durability during repeated insertion and inspection operations, while the Separate Type architecture allows OEM designers to place the processing board away from the inspection point. This module is suitable for handheld inspection tools, repair equipment, and compact visual inspection systems where easy connection and narrow-space access are more important than ultra-high-resolution imaging. |  |
Product Name | 720P 60FPS endoscope camera module with led |
Diameter | 3.9mm |
DSP | USB |
Sensor | OV9734 |
Focusing Range | 10-100mm |
Focal Length | 1.35mm |
F Number | 4.8 |
FOV(D) | 105°*90°*60° |
TV Distortion | ＜-6% |
Steel Sheel | IP67 Waterproof |
Cable length adjustment for different inspection distances.
Connector customization including USB Type-C and alternative connection solutions.
Lens & FOV adjustment for different internal viewing requirements.
Probe mechanical structure customization based on installation space and durability requirements.
Housing and assembly adaptation for handheld tools and OEM inspection devices.
Camera module tuning according to the target host system and application environment.
It is a USB Separate Type Endoscope Camera Module designed for compact inspection devices and narrow-space visual checking.
The D3.9mm probe provides better access to narrow openings and internal structures compared with larger endoscope camera heads.
This model focuses on the balance between small access size, reinforced probe structure, Type-C integration, and OEM flexibility, making it more suitable for professional inspection tools.
Not necessarily. Compatibility depends on the host hardware, operating system, USB protocol support, and driver environment.
Waterproof capability should be confirmed separately. It should not be considered waterproof unless the final mechanical sealing design is verified.
Yes. Cable length, connector solution, mechanical structure, lens configuration, and housing integration can be reviewed according to the OEM project requirements.
Please provide:
target device;
inspection environment;
required probe diameter;
cable length;
viewing distance;
lighting condition;
connector requirement;
host platform.
This information helps determine the suitable endoscope configuration.
