SF-C0310TV-D4
SINCEREFIRST
This compact 4.6mm diameter CMOS image sensor camera module, can deliver high-definition 720P resolution, ensuring crisp visualization even in confined spaces. With a versatile focusing range from 10mm to 100mm and a precise focal length of 1.25mm, it captures intricate details clearly for close-up examinations. The module features a broad 75° field of view for extensive coverage, while minimizing TV distortion to under -10% for distortion-free, reliable imagery. Enhanced by four energy-efficient 0402 white LEDs, it provides consistent illumination in low-light conditions, and its robust IP67 waterproof rating guarantees resilience in demanding, moisture-prone settings. This makes it indispensable for precision tasks across diverse fields. |  |
Resolution: Leverages a CMOS image sensor for sharp 720P output, ideal for capturing fine textures without blur.
Focus Range: Adapts seamlessly from 10mm to 100mm focusing distances, enabling detailed inspections of tiny components.
Lighting and Durability: Integrates four 0402 white LEDs for uniform brightness and an IP67 waterproof build for reliable operation in harsh environments.
1. Educational Tools: Mountable on portable microscopes for interactive classroom demonstrations, such as observing insect anatomy or plant cell structures in biology labs.
2. Home Renovation Gear: Integrated into wall-scanning devices for detecting hidden wiring or pipe leaks during DIY home improvement projects.
3. Recreational Exploration Equipment: Embedded in miniature drones or robotic toys for immersive terrain mapping in outdoor adventure activities.
4. Precision Instrument Maintenance: Integrated into watchmaking repair stations or eyeglass adjustment tools for real-time microscopic inspection of gear mechanisms and hinge alignments during fine adjustments.
Product Name | Endoscope Camera Module |
Features | IP67 waterproof Endoscope Camera |
DSP | USB2.0 UVC |
Sensor | VGA |
Focusing Range | 10mm-100mm |
Waterproof | IP67 |
Focal Length | 1.25mm |
Trademark | SINCERE FIRST |
F Number | 4 |
Fov(D) | 75° |
FAQ
1. What is the difference between medical and industrial endoscope modules?
The medical module emphasizes biocompatibility, sterilization and high image quality, and needs to comply with FDA/CE certification; Industrial modules focus on durability (such as corrosion protection), wide temperature operation (-20°C to 70°C), and special light sources (such as UV).
2. Why does the image appear color bias?
The filter may need to be corrected or replaced by software due to uncalibrated white balance, mismatch of light source color temperature (such as LED mixed with daylight), or aging of the sensor.
3. How to evaluate the cost performance of the module?
For comprehensive resolution, durability, and after-sales support (such as medical modules that require calibration services from manufacturers), industrial scenarios can prioritize MTBF (mean time to failure) indicators.
4. Advantages of AI-assisted endoscope modules?
It integrates real-time lesion labeling (such as polyp recognition), surgical navigation (blood vessel positioning), automatic exposure and other functions, and relies on edge computing chips (such as NVIDIA Jetson) for low latency processing.
5. Why do 4K modules need special transport protocols?
4K@30fps Data volumes up to 12Gbps require Thunderbolt or fiber optic transmission, and some medical devices use compression technologies such as HEVC to reduce bandwidth requirements.
6. How effective are LED fill lights in dark environments?
It is equipped with 6 white leds, and the maximum clear illumination distance in complete darkness is 8cm. If detecting deep holes or reflective surfaces, it is recommended to select a ring-shaped polarized fill light (powered by Type-C), which can eliminate glare and increase the brightness by three times.
7. Where can the IP67 waterproof rating be specifically applied?
IP67 indicates complete dust resistance and short-term water resistance. It is suitable for industrial cleaning environments such as rinsing food processing equipment, outdoor equipment such as agricultural monitoring probes exposed to rain, or disinfection scenarios of medical devices. However, it cannot be used for diving or direct spraying with a high-pressure water gun. For continuous underwater use, it is recommended to select the IP68 upgrade kit.
