SF-C1019USB-D6.0-SV-L25-D140
SINCEREFIRST
| This 6.0mm Diameter Side View USB2.0 UVC Driver Free 720P OV9734 CMOS Sensor Endoscope Camera Module is a reliable imaging solution for sidewall detection, internal side inspection, automobile maintenance and close-range side-view acquisition, compliant with RoHS standards. Built around the OV9734 sensor, it features a 6.0mm diameter side-view structure—its ultra-small 6mm probe easily accesses narrow spaces that conventional front-view modules cannot reach, while the side-view optical design allows direct observation of cavity and pipeline sidewalls without cumbersome probe steering. It outputs 720P images at 30fps, matching the clarity needs of close-range side inspection, and its optical system is optimized for near-distance scenarios: 1.08mm focal length, F4.0 aperture, 95° diagonal FOV and 10–100mm focusing range ensure stable clear imaging at typical endoscopic working distances. With distortion controlled within -10%, it maintains reliable imaging effect for side-view observation. It adopts USB2.0 UVC protocol, supports YUV/MJPEG dual output formats and plug-and-play functionality without driver installation, greatly improving device access efficiency. Equipped with USB 5V/GND/DP/DM interface and independent LED control, it enhances practicality for diverse inspection scenarios, integrating side-view structure, miniaturization, near-distance optimization and driver-free convenience. |  |
2.6.0mm Mini Size: 6mm probe covers narrow spaces inaccessible to conventional front-view modules.
3.10–100mm Near-Distance Optimization: Focus range fits typical endoscopic distances, ensuring stable close-range clarity.
4.UVC Driver-Free Fast Deployment: Applies standard USB video protocol, plug-and-play without driver installation.
Keywords | 4pcs LED Endoscope Camera Module |
Sensor | OV9734 |
LED | 4pcs LED |
FOV(D*H*V) | 95°*85°*43.5° |
Focusing Range | 10-100mm |
Focal Length | 1.08mm |
FOV(D) | 90° |
TV Distortion | <-10% |
Output | USB2.0 UVC |
F Number | 3.58 |
Resolution | 720P Max 30fps |
Features | Mini Endoscope Camera |
1. Difference between side-view and front-view modules?
Side-view modules image perpendicular to the probe axis for lateral inspection, while front-view modules image along the axis for forward observation.
2. Impact of the 10–100mm focus range?
This is the typical working distance for side inspection. The module maintains sharp focus within this range, with image quality degrading outside of it.
3. Why is < -10% distortion acceptable?
Negative distortion (barrel distortion) expands the Field of View (FOV) in compact systems. This represents a trade-off between size and angle, which can be corrected via algorithms.
