Frame rate, measured in frames per second (fps), is the number of images an endoscope camera captures and displays each second. It directly influences how smooth the video appears, how clearly fast motion is captured, and how well the camera performs in low light. Whether you are using a medical endoscope camera module, a mini camera module for industrial borescopes, or a USB Camera Module for DIY inspection, understanding frame rate helps you choose the right tool for your task.
In simple terms, a higher frame rate means smoother motion. Standard video is 30 fps, which is smooth enough for most human observation. However, if the camera or the subject moves quickly – such as a surgeon moving a laparoscope, a water jet inside a pipe, or a vibrating turbine blade – a higher frame rate like 60 fps or even 120 fps will capture the action with much less blur and judder.
Conversely, a lower frame rate (e.g., 15 fps) can make video look choppy but allows the camera to keep the shutter open longer for each frame, which improves low‑light performance.
The most important trade‑off is between frame rate and low‑light performance. To capture a frame, the sensor must be exposed to light for a certain period. Higher frame rates require shorter exposure times per frame.
At 30 fps, each frame can be exposed for up to about 33 milliseconds.
At 60 fps, each frame can be exposed for only about 16 milliseconds – half the time.
Less exposure time means less light collected, so the image will be darker or noisier. Therefore, if you are using an endoscope camera module in a dark cavity with limited LED illumination, running at 60 fps may produce a dim, grainy image. Lowering the frame rate to 30 fps or 15 fps will brighten the image but make motion appear less fluid.
Medical endoscopy – In procedures where tissue moves rapidly (e.g., beating heart, vocal cords, peristalsis), 60 fps or even 100 fps reduces motion blur and helps surgeons see fine details. A cmos camera module with global shutter and high frame rate is ideal.
Industrial inspection – When inspecting fast‑moving machinery (spinning turbines, conveyor belts), a higher frame rate freezes motion, allowing you to see cracks or defects that would otherwise be blurred. A mini camera module with 60 fps capability can be used in a borescope to inspect engine cylinders at different crank angles.
Robotics and automation – A robot arm or AGV needs low latency and high frame rate to react quickly to its environment. A USB Camera Module streaming at 60 fps over USB 3.0 can provide real‑time feedback for vision‑guided picking.
Static or slow inspection – Examining a pipe interior, a wall cavity, or a stationary part does not require high frame rate. 30 fps or even 15 fps is sufficient, and the saved exposure time can be used to brighten the image.
Extremely low light – If you are working in near‑darkness (e.g., a sewer line with dim LED illumination), dropping the frame rate to 15 fps or 10 fps can double or triple the exposure time, significantly improving brightness and reducing noise.
Battery‑powered devices – Higher frame rates consume more power because the sensor and processor must handle more data per second. For a hand‑held USB Camera Module running on battery, 30 fps is a good compromise.
A standard UVC camera module (USB Video Class) typically supports multiple frame rates. For example, a 1080p endoscope camera module might offer 30 fps at full resolution and 60 fps at 720p. The host computer selects the desired frame rate and resolution via the UVC protocol.
When using a UVC camera module, keep in mind that USB 2.0 bandwidth (about 40 MB/s) limits 1080p to about 30 fps when using MJPEG compression. To achieve 1080p at 60 fps, you need USB 3.0 or a lower compression format. An OEM camera module can be designed with a USB 3.0 bridge to support higher frame rates.
Application | Recommended Frame Rate | Reason |
|---|---|---|
Routine medical endoscopy (GI tract) | 30 fps | Smooth enough, good low‑light |
Cardiac or vocal cord endoscopy | 60 fps or higher | Captures fast tissue motion |
Industrial borescope – static inspection | 30 fps | Balanced performance |
Industrial – moving conveyor | 60 fps | Reduces motion blur |
Sewer / pipe inspection | 15‑30 fps | Low light often needs longer exposure |
Hand‑held USB endoscope (battery) | 30 fps | Good compromise on power |
For a UVC camera module (most USB endoscopes), the operating system or application selects the frame rate. In OpenCV, you can set cv2.CAP_PROP_FPS. In VLC, you can choose the desired frame rate from the capture device options.
For an OEM camera module with a dedicated DSP, the firmware may allow you to change the frame rate via OSD menu or serial commands.
For a mini camera module using MIPI CSI‑2 (e.g., on a Raspberry Pi), you can set frame rate in the libcamera command line: libcamera-vid --framerate 60.
Suppose you need to inspect small cracks inside a slowly rotating turbine blade. The environment is moderately lit. A standard 30 fps endoscope camera module would work fine – the motion is slow, and 30 fps provides smooth video.
But if you need to inspect a high‑speed conveyor carrying small electronic parts at 2 m/s, 30 fps may produce motion blur. A 60 fps USB Camera Module with global shutter would capture sharp images of each component.
If you are building a custom product, an OEM camera module can be designed to support multiple frame rates – for example, 60 fps for fast inspection mode and 15 fps for low‑light power‑saving mode.
Frame rate is a critical parameter for endoscope camera performance. Higher frame rates (60 fps and above) provide smoother motion and capture fast action with less blur, but they require more light, more bandwidth, and more processing power. Lower frame rates (15‑30 fps) improve low‑light sensitivity, reduce data rates, and extend battery life.
When selecting an endoscope camera module – whether a mini camera module for tight spaces, a USB Camera Module for portable use, a UVC camera module for plug‑and‑play, an OEM camera module for a custom device, or a cmos camera module for embedded vision – consider the speed of the subject, the available light, and the desired image quality. Often, 30 fps is a solid starting point; move to 60 fps when motion matters, and drop to 15 fps when darkness is the main challenge.
If you need a custom endoscope camera module with a specific frame rate, low‑light optimization, or a particular interface, contact Sincere. We design and manufacture OEM camera modules tailored to your medical, industrial, or consumer application.
