High Resolution OCHFA10 Sensor Side-View medical inspection Endoscope Camera Module

This High-Resolution OCHFA10 Sensor Side-View Medical Inspection Endoscope Camera Module is a high-performance device specifically designed for precise imaging in tight spaces. Integrating ultra-miniaturized dimensions with outstanding imaging capabilities, it aims to provide a critical optical solution for visual inspection deep into human natural cavities or minimally invasive incisions. Equipped with the OCHFA10 sensor, the module features a lens diameter of only 1.5mm and adopts a side-view imaging design, allowing flexible access to fine lumens or gaps between precision structures for inspection. Its core parameter configuration is comprehensive and excellent: boasting a resolution of 720x720 pixels to ensure clear and distinguishable image details; a focal length of just 0.418mm with a focusing range of 5-50mm, enabling accurate capture of micro-targets at different distances; horizontal and vertical field of view of 86° each, paired with an F5.0 aperture, achieving a balance between a wide field of view and excellent depth of field; distortion controlled below -11%, presenting true and undistorted imaging results to provide a reliable basis for diagnosis and inspection. The module uses a 3-5V wide voltage power supply, is equipped with a MICRO USB-5P interface, and is manufactured through advanced SMT technology and AA (Active Alignment) process, ensuring the stability and consistency of mass production. It has also passed multiple international certifications including RoHS, CE, FCC, and REACH, fully complying with the compliance requirements of the global market.

Product Advantage ◢

1. Ultra-Mini Side-View Optical Breakthrough: The 1.5mm world-leading ultra-miniature lens, combined with an 86° wide-field side-view optical path, breaks through the observation blind spots of traditional forward-view lenses. It easily penetrates the lateral gaps of complex precision structures, realizing full-coverage inspection of side walls that traditional endoscopes cannot reach.
2. High-Fidelity Microscopic Imaging System: The OVCHFA10 sensor is equipped with 1.008μm micro-level pixels, and its 700x700 resolution is 75% higher than that of standard products. It delivers medical-grade color reproduction and detail resolution within a working distance of 5-50mm, with distortion control superior to similar products.
3. All-Scenario Precise Focus Architecture: The 0.418mm ultra-short focal length optical design, combined with a manual fine-tuning mechanism, enables fast and accurate focusing from otolaryngological cavities to industrial millimeter-scale pipelines; the F5.0 aperture ensures sufficient light transmission, with no shadow dead angles during macro observation.
4. Industrial-Grade Reliability Design: Precision SMT placement combined with AA active optical alignment process guarantees the optical axis consistency of mass-produced modules; the separate structure supports customers' customized mechanical integration; passing four international certifications, it meets the biocompatibility requirements of medical equipment and the harsh environmental requirements of industrial equipment.

5. Zero-Threshold Deployment Capability: The standard UVC protocol supports plug-and-play on Windows, Linux, and Android systems, with real-time transmission at 30fps without delay; the 1.5mm module diameter is compatible with mainstream endoscope handles, significantly shortening customers' product development cycles.

Application Of Endoscope Camera Module ◢

• Otolaryngology Endoscope: Used for sinusitis examination, vocal cord polyp observation, and middle ear tympanic cavity exploration. The side-view design facilitates the observation of complex structures such as the maxillary sinus ostium and eustachian tube orifice.

• Dental Periodontal Endoscope: Penetrates deep into periodontal pockets to intuitively observe plaque, calculus, and periodontal tissue damage on the root surface under the gums, assisting in precise treatment.

• Minimally Invasive Surgery Endoscope: Can serve as the imaging core for instruments such as arthroscopes and intervertebral foramen scopes, used to observe articular cartilage wear, ligament damage, or conditions within the spinal canal.

• Endoscope-Assisted Inspection Equipment: Integrated into ultra-fine endoscopes such as vascular endoscopes and biliary cholangioscopes, used to evaluate vascular intimal plaques and internal biliary duct lesions.

Technical Parameters ◢

FAQ ◢

1.  How to select between a side-view lens and a forward-view lens?

The side-view lens is suitable for lumen side wall observation (e.g., blood vessels, pipelines), while the forward-view lens is suitable for end-face target detection. This module can achieve 360° circular scanning observation through rotation.

2. Does the 1.5mm diameter of the module refer to the size of the entire product?

No. The 1.5mm specifically refers to the diameter of the front probe part including the optical lens, which is the key dimension for accessing the human body or narrow spaces.

3. Can it be directly connected to my laptop for use?

Yes. The module adopts a USB 2.0 interface and supports the UVC protocol. It is usually recognized as a camera device without the need to install additional drivers on Windows, macOS, Linux, and Android systems, making it very easy to use.
