Many endoscope camera module projects start with one question: “How many pixels does the camera have?”
But for OEM customers, pixel count is only one part of the decision.
A camera module must also match the probe diameter, working distance, FOV, lighting method, waterproof requirement, cable length and host system.
The SF-C5015USB-D6 is a D6.0 integrated USB endoscope camera module using the GC5035 5MP sensor. It supports YUV / MJPEG output at 2592×1944@30fps, offers an 88° FOV, provides 20–50mm / 50–100mm focusing range options, supports IP67, and uses a no-LED structure for projects where the customer controls the device-level lighting design.
Its strongest value is not only “5MP.” Its real value is the combination of higher image detail, D6.0 integrated structure, IP67 support and external lighting flexibility for OEM endoscope or inspection device development.
Basic 0.3MP or 1MP modules can be enough for simple visual confirmation. They may help users check whether a channel is blocked, whether a component is present or whether a structure is generally visible.
But some customers need more image detail.
They may need to observe:
Surface texture
Material condition
Small visible defects
Internal structure detail
Component edges
Inspection records with better image clarity
For these projects, a 5MP module can provide a stronger imaging foundation than lower-resolution options.
The SF-C5015USB-D6 supports 2592×1944@30fps output, which makes it suitable for applications that require higher-detail visual observation while still using a compact USB endoscope camera structure.
The SF-C5015USB-D6 is an integrated USB endoscope camera module.
Key specifications include:
D6.0 camera diameter
GC5035 sensor
5MP imaging class
ALL integrated type
USB output
YUV / MJPEG format
2592×1944@30fps output
No built-in LEDs
25mm front length
Plastic lens
88° FOV
20–50mm / 50–100mm focusing range options
IP67 support
1m standard cable
3m maximum cable length
No dimming
Type-A connection listed
The catalog does not list a separate main board size for this model. Mechanical details should still be confirmed during project communication if the final device has strict space limits.
Some customers begin with a smaller or lower-resolution endoscope module and later find that the image does not show enough target detail.
The SF-C5015USB-D6 gives these customers a higher-detail 5MP option.
It can be evaluated when the application needs better image clarity than basic visual checking, but still requires an endoscope-style camera head and USB output.
However, customers should not assume that 5MP alone guarantees inspection success.
Image usability also depends on lens, focus range, lighting, target material, FOV and software display.
Many high-detail camera modules are not always suitable for wet or cleaning-sensitive environments.
The SF-C5015USB-D6 supports IP67, which makes it relevant for applications where moisture, cleaning, liquid exposure or harsh inspection conditions may be part of the device requirement.
However, OEM customers should understand one important point:
Module-level IP67 does not automatically guarantee final device waterproof performance.
The complete device still depends on housing design, sealing structure, cable exit protection, connector protection, adhesive and assembly process.
This model provides two focusing range options:
20–50mm
50–100mm
This is a critical selection factor.
If the target is normally very close to the lens, the 20–50mm option may be more suitable.
If the target is farther away, the 50–100mm option may be evaluated.
Customers should measure the actual camera-to-target distance before requesting samples.
A 5MP image outside the correct focus range may still look unclear.
The module provides an 88° FOV.
This is a practical middle direction for many inspection devices.
It is wider than a narrow local-view camera, but not as extreme as 120° or 140° ultra-wide endoscope modules.
For customers, this can help balance target detail and surrounding context.
An 88° FOV can be useful when the user needs to see the inspection target clearly while still maintaining enough surrounding view for orientation.
This model has no built-in LEDs.
For some buyers, this may appear to be a limitation.
For OEM customers with their own lighting design, it can be an advantage.
No built-in LEDs can help the customer design:
External ring lighting
Side illumination
Separated light source
Device-level brightness control
Lower-reflection lighting geometry
Customized illumination for target materials
This is especially useful when built-in LEDs may cause glare, overexposure or unwanted heat near the camera head.
The SF-C5015USB-D6 can be evaluated for:
Industrial endoscope devices
High-detail cavity inspection
Equipment internal observation
Pipe or tube inspection with external lighting
Maintenance inspection systems
OEM USB visual inspection devices
Custom waterproof-supported inspection probes
Medical or veterinary visualization device development at component level
For medical-related applications, the module should be evaluated as an imaging component. Final device safety, cleaning validation, compliance and certification should be handled at the complete-device level.
Choose SF-C5015USB-D6 when your project needs:
D6.0 camera diameter
5MP image output
2592×1944@30fps
USB integration
IP67 support
External or device-level lighting
88° FOV
20–50mm or 50–100mm working distance
Integrated camera structure
1m standard cable
Cable evaluation up to 3m
It is especially suitable for OEM customers who need higher detail and already have a lighting strategy.
Another module may be better if the project needs:
Built-in LED illumination
LED dimming inside the module
Smaller diameter below 6mm
Ultra-wide 120° or 140° FOV
Very close focus below 20mm
Longer cable beyond 3m
AI or measurement-level inspection without further system validation
A finished plug-and-play consumer endoscope device
The correct model should be selected according to the complete inspection system.
Customers should test:
Image detail at the real working distance
20–50mm vs 50–100mm focus configuration
External lighting design
Reflection and shadow
IP67 performance after final assembly
88° FOV coverage
Host compatibility with YUV / MJPEG output
Cable length and signal stability
Mechanical fit of the 25mm front section
Actual user workflow
Testing should be performed with the real target material and lighting method, not only with a desktop image chart.
Before requesting a quotation, provide:
Application scenario
Medical, industrial or other device direction
Required camera diameter
Target size
Actual working distance
Need for 20–50mm or 50–100mm focus range
Image detail requirement
External lighting method
Target surface material
Waterproof requirement
Cable length
Host device
Type-A system compatibility requirement
Sample quantity
Estimated production volume
Mechanical drawing if available
The SF-C5015USB-D6 is a D6.0 5MP USB endoscope camera module for OEM customers who need higher-detail imaging, IP67 support and external lighting flexibility.
Its value is not simply higher resolution.
The real value is the combination of 2592×1944@30fps output, GC5035 sensor, D6.0 integrated structure, 88° FOV, selectable working distance and waterproof-supported module design.
Need a 5MP USB endoscope camera module for a higher-detail OEM inspection device?
Send your application, working distance, lighting design, waterproof requirement and host system information to SincereFull. Our team can help evaluate whether SF-C5015USB-D6 fits your project.
